Aputure Storm 400x LED Blair Light Engine Kit | V-Mount
BLAIR: The Best Tunable White Light
The Aputure STORM 400x is a 400W tunable white, high-fidelity point source LED light designed for filmmakers, photographers, and lighting professionals. Powered by Aputure's revolutionary BLAIR (Blue/Lime/Amber/Indigo/Red) light engine, the STORM 400x delivers unmatched white light quality with advanced +/- green adjustability. Indigo emitters enhance fluorescing materials, replicating the natural look of daylight and tungsten sources.
Despite its compact design, the STORM 400x's output matches or exceeds many higher-wattage LED lights, making it a powerful yet portable solution for both studio and on-location shoots.
Color Tuning & Advanced Control
With Limited HSIC+ and x,y control modes, the STORM 400x achieves vibrant, saturated colors across more than 70% of the Rec.2020 color space. From deep crimson sunsets to warm sodium vapor ambers, you can create cinematic color effects without the need for gels.
ProLock Locking Bowens Mount
The ProLock Bowens mount securely holds even the heaviest modifiers and optics, ensuring perfect alignment during demanding shoots. This innovative mount system guarantees reliability and ease of use on set.
Compact Powerhouse
Pair the STORM 400x with the CF7 Fresnel lens for an intense beam capable of delivering over 23,000 lux at 3m. This makes it an ideal tool for key lighting, backlighting, or powerful fill lighting in professional productions.
Professional Control Options
The STORM 400x integrates seamlessly into professional workflows with:
- Sidus Bluetooth Mesh for wireless control
- CRMX and 5-Pin DMX compatibility
- Support for advanced lighting control software
IP65 Weather Protection
Designed for all-weather use, the STORM 400x offers IP65-rated dust and weather resistance. Sealed connectors and components ensure that both the lamphead and control box remain protected, even during outdoor shoots in rain or harsh environments.
Key Features
- 400W tunable white high-fidelity COB LED light
- Advanced BLAIR light engine with +/- green adjustment
- Color tuning with over 70% Rec.2020 coverage
- ProLock Bowens mount for secure modifier attachment
- Wireless control via Sidus Mesh, CRMX, and 5-pin DMX
- IP65 dust and weather protection
- Output exceeding 23,000 lux at 3m with Fresnel
What's in the Box?
- 1x STORM 400x Lamp Head
- 1x STORM 400x Control Box
- 1x Lightning Clamp
- 1x 35° Angle Hyper Reflector
- 1x STORM 400x Head Cable (3m)
- 1x AC Power Cable (6m)
- 1x Bowens Mount Protection Cover
- 1x Soft Carrying Case
| CCT | Distance | No Reflector | 35º Reflector | CF7 Full Spot (15º) | CF7 Full Flood (40º) |
|---|---|---|---|---|---|
| 2,500K | 1m | 20,590 lux 1,913 fc | 49,200 lux 4,571 fc | 179,800 lux 16,703 fc | 40,600 lux 3,772 fc |
| 3m | 2,361 lux 219 fc | 3,850 lux 358 fc | 17,700 lux 1,644 fc | 4,780 lux 444 fc | |
| 3,200K | 1m | 25,600 lux 2,378 fc | 61,600 lux 5,723 fc | 225,200 lux 20,921 fc | 51,000 lux 4,738 fc |
| 3m | 2,964 lux 275 fc | 4,850 lux 451 fc | 22,210 lux 2,063 fc | 6,020 lux 559 fc | |
| 4,300K | 1m | 27,350 lux 2,541 fc | 65,400 lux 6,076 fc | 237,300 lux 22,045 fc | 53,900 lux 5,007 fc |
| 3m | 3,140 lux 292 fc | 5,120 lux 476 fc | 23,470 lux 2,180 fc | 6,400 lux 595 fc | |
| 5,600K | 1m | 27,100 lux 2,518 fc | 64,600 lux 6,001 fc | 236,700 lux 21,989 fc | 53,900 lux 5,007 fc |
| 3m | 3,110 lux 289 fc | 5,090 lux 473 fc | 23,260 lux 2,161 fc | 6,380 lux 593 fc | |
| 7,500K | 1m | 25,700 lux 2,388 fc | 61,600 lux 5,723 fc | 225,200 lux 20,921 fc | 51,500 lux 4,784 fc |
| 3m | 2,960 lux 275 fc | 4,840 lux 450 fc | 22,110 lux 2,054 fc | 6,100 lux 567 fc | |
| 10,000K | 1m | 24,160 lux 2,244 fc | 57,800 lux 5,370 fc | 212,600 lux 19,751 fc | 48,500 lux 4,506 fc |
| 3m | 2,790 lux 259 fc | 4,550 lux 423 fc | 20,760 lux 1,929 fc | 5,740 lux 533 fc |
| Specification | Details |
|---|---|
| TM-30 RG (Average) | 100 |
| Max Power Consumption | 500W |
| Max Power Output | 400W |
| Operation Voltage | 100V ~ 240V / 50-60 Hz |
| USB-A Power Port Specifications | Out 5V/0.5A |
| Battery Mount Operating Voltage | 14.4V |
| Weather Resistance Rating | IP65 |
| Native COB Beam Angle | 57º |
| Included Reflector Beam Angle | 35º |
| Data Ports | 1x 5-Pin DMX In, 1x 5-Pin DMX Out |
| Operating Temperature | -20°C ~ 45°C / -4°F ~ 113°F |
| Storage Temperature | -40°C ~ 80°C / -40°F ~ 176°F |
| Lamp Head Fan Noise Levels (1M) Smart Mode | 36 dBA |
| Lamp Head Fan Noise Levels (1M) High Mode | 33 dBA |
| Lamp Head Fan Noise Levels (1M) Medium Mode | 29 dBA |
| Lamp Head Fan Noise Levels (1M) Silent Mode | 0 dBA |
| Component | Weight (kg) | Weight (lbs) |
|---|---|---|
| Lamp Head with Yoke | 3.95 kg | 7.99 lbs |
| Control Box | 3.00 kg | 6.07 lbs |
| Head Cable | 0.51 kg | 1.03 lbs |
| AC Power Cable | 0.59 kg | 1.19 lbs |
| 35° Reflector | 0.25 kg | 0.51 lbs |
| Lightning Clamp | 0.65 kg | 1.32 lbs |
