Lex Lex-Loc Female 15a Cage Clamp Edison Connector Hospital Grade
Item Code: X515C
$15.70
$12.18
Description
Lex Lex-Loc Female 15a Cage Clamp Edison Connector Hospital Grade
2P 3W 5-15 CL, LEX Connector All Black Description: 2P3W 15A 125 VAC NEMA 5-15 LexLoc?Edison Female Connector Catalog Number: X515C Markets Served: Theatrical, Motion Picture, Live Events, Industrial, Military Application: Allows user to build extension cords and attach new or replacement plugs or appliances. Features & Benefits:- Cage clamp terminations cannot loosen, eliminating the main cause of device failure.
- Does not require tools; simple open and close the terminals.
- Saves labor.
- Two fast travel assembly screws save labor.
- All black color blands into scenery.
- Beefy external cord clamp provides excellent strain relief to a wide range of cords. Specifications: DESIGNED FOR DURABILITY
- Lex-Loc? devices meet or exceed Hospital Grade U.S. tests.
- Devices conform to U.S. Standards for hospital equipment, #498 and #544, including:
- Abrupt plug removal (parallel to wall) test
- Ground contact temperature test
- Ground resistance test
- Grounding contact overstress test
- Assembly security test
- Mold stress relief test
- Crush test
- Cord grip strain relief tests
- Static cord pull test
- Rotary cord pull test
- Impact resistance test
- Mechanical drop test CONSTRUCTION:
- Housing and Body: Nylon ? Tough and resistant to a wide range of chemicals.U.L.Recognized for 125?C continuous use.
- U.L.94V-2 Flammability Index.
- Beveled design to resist snagging. Blades and
- Contacts: Solid brass for excellent conductivity
- Terminal Cover: Clear polycarbonate ? terminals visible
- Assembly Screws: Two U-drive combination slot/crosshead MECHANICAL:
- Accommodates 18/3 SJ through 10/3 S cable Cord Accommodation (with inserts): .300''- .430'' Cord Accommodation (inserts removed): >.430''- .655'' ELECTRICAL:
- Dielectric Withstand Voltage: >3,000V
- Heat Rise: Maximum 30?C after 100 cycles at 150% of rated current
- Current Interrupting: Yes
- U.L.Listed File E57672
- C.S.A.Cer tified File LR81290
Reviews
1 Reviews
Plug & Play
I recently rebuilt a number of Lutron NT dimmers for my light kit. In the past I really struggled with securing 12 gauge wire with screws and keeping it secured. I decided to give the Lex Lex-Loc Edison plugs a go. They have a locking lever that you open, insert your wire and then fully close the lever to terminate the connection. It takes a bit finesse and luck using 12 gauge wire. Smaller gauge wire should be a breeze to install and terminate. In the end I'm a huge fan of the Lex Lex-Loc system and plan to continue using them on future builds.
Locking lever termination is ingenious. Properly locked, it should remain locked.
Larger gauge wire can cause character development (patience).
