Nanlite PavoTube II 30X 4' RGBWW LED Pixel Tube with Internal Battery
Nanlite PavoTube II 30X 4' RGBWW LED Pixel Tube with Internal Battery
The Nanlite PavoTube II RGBWW LED Pixel Tubes are the next evolution of Nanlite's signature light fixtures. These second-gen LED Tubes have been refined based on feedback from creators around the globe with features including pixel-based special effects, brighter output, more uniform diffusion, robust metal housings, DMX compatibility, and wireless 2.4G and Bluetooth control with the free NANLINK mobile app for iOS and Android.
Get Unique, Studio Quality Lighting Anywhere
With an expanded and more precise color temperature range from 2700K-12000K with green to magenta adjustment, an average CRI of 95, an average TLCI of 98, plus full-spectrum RGB hue and saturation control, the PavoTube II 30X 4' RGBWW LED Pixel Tube packs studio-quality lighting into a hardy, go-anywhere package. From a Next-Generation LED Tube
Nanlite drew on the feedback from PavoTube owners across the world to evolve their LED Tube design. Enhancements include brighter output from a larger illumination area with more uniform diffusion, a pixel density of 16 to create eye-catching animated effects, an upgraded control panel with locking buttons, DMX compatibility, and full wireless control through 2.4G and Bluetooth with the free NANLINK mobile app for iOS and Android. With No Cords Needed
Powered an internal 4400mAh Li-ion battery, the PavoTube II 30X can run for 1 hour and 36 minutes at full brightness completely untethered. Full battery recharge is achieved in 3.5 hours via the included AC adapter, which can also power the Pavotube II 30X during longer shoots. Pixel Based Special Effects
In addition to 15 adjustable practical special effects, PavoTube II 30X features 10 new pixel-based effects expanding the creative possibilities further than ever before. Pixel-based effects include Hue Loop, CCT Loop, INT Loop, Multi-color, Gradient, Scrolling, Marching, Flame, Rainbow, and Driving. Practical effects include Hue Loop, CCT Loop, INT Loop, CCT Flash, HUE Flash, CCT Pulse, Hue Pulse, Storm, Police Car, TV, Paparazzi, Candle/Fire, Disco, Bad Bulb, Firework, Explosion, and Welding. And A Robust Metal Housing
The PavoTube II 30X's upgraded metal housing makes worrying about an accidental drop or risky light placements a thing of the past. Plus, three incorporated ΒΌ-20" receivers greatly expand mounting options.
Lux / Foot Candles
- Distance and CCT Distance and Color
- @ 0.5m 2700K 2744 lux / 254.9 fc @ 0.5m Red 1090 lux / 101.2 fc
- @ 1m 2700K 686 lux / 63.7 fc @ 1m Red 272 lux / 25.2 fc
- @ 2m 2700K 174 lux / 16.1 fc @ 2m Red 69 lux / 6.4 fc
- @ 3m 2700K 78 lux / 7.2 fc @ 3m Red 30 lux / 2.7 fc
- @ 0.5m 3200K 2756 lux / 256 fc @ 0.5m Green 2343 lux / 217.6 fc
- @ 1m 3200K 688 lux / 63.9 fc @ 1m Green 586 lux / 54.4 fc
- @ 2m 3200K 175 lux / 16.2 fc @ 2m Green 144 lux / 13.3 fc
Technical Data
- CRI: Average 97
- TLCI: Average 98
- Warranty: Limited 2 Year Warranty (Extend to 3 Years Total With Online Registration)
- Color Temperature (Kelvin): 2700K-12000K
- Lumen Output 3200K: 1188
- Lumen Output 5600K: 1278
- Dimming: 0-100%
- DMX Control: Yes
- Compatible Wifi Adapter: Nanlink WS-TB-1 Transmitter box
- Compatible Remote: WS-RC-C2 remote control
- Wireless Control Type: 2.4GHz, Bluetooth, DMX/RDM
- Frequency: 2.4Ghz
- Accessory Port(s): No
- Depth Rating: IP 20
- Mount: T12, 3x 1/4 20", Magnets
- Operating Temperature: ta45℃
- Cooling System: No
- Power Source: DC15V/4A
- Max Power Consumption: 36W
- Electrical Load Capacity: 81.4W
- Amp-Hours: 4400mAh
- Includes Rechargeable Battery: Yes
- Number of Battery Cells: 10
- Battery Capacity (Wh): 81.4
- Battery Chemistry: Li-Ion
- Compatible D-Tap Adapter: Nanlite CB-DT-DC D-Tap cable with DC Socket
- Battery Included: Yes
- Charger: AC Adapter
- Battery Maximum Output Voltage: 18.5V
- Battery Required: Yes
- Charge Time to Full (Hours): About 3 hours 30 mins
- Runtime @ 100% Brightness (Hours): 1h 36 mins
- Runtime @ 50% Brightness (Hours): 3h 7mins
- Runtime @ 10% Brightness (Hours): 11h 45 mins
- Product Diameter (cm): 4.3
- Product Diameter (in): 1.7
